SZL floating head type oil heater is composed of high-efficiency heat exchange tube, steel tube, aluminum tube and composite. The heat sink formed by rolling on professional machine tool is combined with steel tube and aluminum tube, which has small thermal resistance, good heat transfer performance, high strength, small flow loss and strong corrosion resistance. Especially in the high temperature operation, the use of floating head oil heater, huge thermal stress, heat pipe can automatically stretch, shrink, ensure the service life of the equipment.

Note: SZL floating head oil heater has different surface pipe length, pipe number and row number, which can be made up of various specifications, and its process can be adjusted according to the needs of users. The height of the second row pipe is 180 mm, the third row pipe is 200 mm, the sixth row pipe is 360 mm, and the eighth row pipe is 420 mm.

Vertical section of floating head schematic diagram
